BZD 132 Led Explosion Proof Light
Designed for Explosive Atmospheres Zone 1 and Zone 2;
Designed for Combustible Dust Zone 21 and Zone 22;
Designed for IIA, IIB and IIC Groups Explosive Atmospheres;
Designed for Temperature Classifications T1~T6;
Designed for Explosive Hazardous Locations Such as Oil Refinery, Storage, Chemical, Pharmaceuticals, Textile, Printing, Military Industries, Etc.
 |
 |
Enclosure is Die Casted of High-Strength Aluminum Alloy with High Voltage Electrostatic Powder Coated Surface After Shot Blasting;
LED Light Source Use High Brightness, Long Life International Famous Brand Chip.
The Special Constant Current Power Supply with High Efficiency, Low Power Consumption and Constant Output Power, and Features of Short Circuit, Open Circuit and Overheating Protection Ensures That LED Lamp Working Reliably, High-Light Effect, Energy Saving and Long Service Life;
Adopt Integral Structure, and Divided into the Design of Structure of Lamp Cavity, Electric Cavity and Wiring Cavity. Lamp Cavity is Completely Separated from Electric Cavity. Structure of Special Heat Dissipation in the Middle Ensures That the Heat Generated from Lamp and Power Gives Out;
The Wiring Board is of New Design. The Wire Shall be Accessed to the Wiring Board in Horizontal Direction and Fastened by Bolts in Vertical Direction When Installing, Which Can Avoid Shedding During Long-Time Service Period;
Transparent Covers are Made of Toughened Glass with Functions of High Temperature Resistance and Heat Resistance. The Prismatic Anti-Glare Design Can Effectively Reduce Glare;
The Light Fittings Adopt Explosion Protection Structure of Thread, Spigot and Cementing with Good Explosion Protection Performance, Which Meet the Requirements of IIC.
Each Joint of Light Fittings is with Sealing Structure, Sealing Rings are Made of Silicone Rubber , Which Has Features of High Temperature Resistance and Anti-Aging, The Ingress Protection of Enclosure is IP66;
Enclosure Adopts High Voltage Electrostatic Powder Coated Surface After Shot Blasting and Chemical Treatment, and the Corrosion Resistance Reaches to Wf2;
Emergency Function is Available as Per Request.
Steel-Pipe Laying Wire.
The Light Fitting is with LED When Delivery, Can be Used While It is Powered.
Please Select Products as Per Model Code.
For Example: If Need Lamp and Ceiling Mounting Type, the Model Shall Be: LED132-40X.
Compliance With: GB3836.1, GB3836.2, GB12476.1, GB12476.5, IEC60079-0, IEC60079-1, IEC61241-0, IEC61241-1;
Explosion Protection: Ex d IIC T6 Gb/Ex tD A21 IP66 T80℃; Ex d IIC T5 Gb/Ex tD A21 IP66 T95℃
Working Voltage: AC100~240V, 50/60Hz
Lamp: LED;
Rated Power: 20W, 30W, 40W, 50W, 60W, 80W
Luminous Efficiency: ≥110 lm/W;
Power Factor: ＞0.95;
Color Temperature: 5500K~6500K;
Color Rendering Index: Ra>75;
Ingress Protection: IP66;
Corrosion Resistance: WF2;
Cable Entry: G3/4″;
Cable Outer Diameters: Φ9mm~Φ14mm
Emergency Device Parameters
Charging Time: ≤24h
Emergency Start Time: ≤0.25S
Emergency Lighting Time: ≥90min
