Designed for Explosive Atmospheres Zone 1 and Zone 2;
Designed for Combustible Dust Zone 21 and Zone 22;
Designed for IIA, IIB and IIC Groups Explosive Atmospheres;
Designed for Temperature Classifications T1~T6;
Designed for Factory Area and Street Road.
Designed for Explosive Atmospheres Zone 1 and Zone 2;
Designed for Combustible Dust Zone 21 and Zone 22;
Designed for IIA, IIB and IIC Groups Explosive Atmospheres;
Designed for Temperature Classifications T1~T6;
Designed for Factory Area and Street Road
 |
Material
Enclosure is Made of Aluminum Alloy Whose Content of Magnesium and Titanium is Less Than 7.5%. The Impact Resistance is over 7J;
Product is Consists of a Light Source Cavity and an Electrical Chamber;
The Transparent Covers are Made of Toughened Glass with Good Light Transmittance and Impact Resistance Which Can Withstand the Impact of 4J;
LED Module
High Brightness LED Lamp is Equipped with High Efficiency Constant Power Supply.
The Aluminum Base Board is Made of Aluminum Plate, Which is High Thermal Conductive Small Thermal Resistance and Fast Heat Conduction.
Special Designed Circuit Module is with Good Protection Function.
The Function of Luminous Flux Compensation Can Reduce Lumens Depreciation and Ensure the Luminous Efficiency of LED Lamp.
With the Protection Functions of over Voltage, over Current and Inrush Current;
Heat Dissipation
Enclosure is Die Casted of Aluminum Alloy with High Voltage Electrostatic Powder Coated Surface After Shot Blasting to Ensure Good Weather Resistance.
Conductive Silicon Wafer Between LED Aluminum Base Board and Aluminum Alloy Enclosure, Which Can Improve the Heat Transmission and Lower the Temperature of the LED Aluminum Base Board.
Numbers of Heat Dissipation Fins on the Enclosure Can Enlarge the Area of Enclosure and Effectively Dissipate Heat Through Air Flow, Which Controls LED Working Temperature in Optimum Range, Lowers LED Light Failure and Extends the Service Life of the Led;
Others
No Electromagnetism and Ultraviolet Radiation, Provides Good Illumination to Users Who Work Indoor for a Long Time.
This Product is of Free Maintenance with Energy Conservation and Environmental Protection;
Cable or Steel Pipe Wiring.
Compliance with: GB3836.1, GB3836.2, GB3836.3, GB3836.9, GB12476.1, GB12476.5, IEC60079-0, IEC60079-1, IEC60079-7,
IEC60079-18, IEC61241-0, IEC61241-1;
Explosion Protection: Ex d e mb IIC T6 Gb/Ex tD A21 IP66 T80℃;
Rated Voltage: AC100~240V 50/60Hz;
Lamp: LED;
Rated Power: 100W, 120W, 150W, 200W;
Luminous Efficiency: >110lm/W;
Power Factor: >0.95;
Color Temperature: 5500K~6500K;
Color Rendering Index: Ra>75;
Ingress Protection: IP66;
Corrosion Resistance: WF2;
Cable Entry: G3/4″;
Cable Outer Diameters: Ф9mm-Ф15mm
